Security Cameras Museum

Created by Chris Sandu, Modified on Tue, 18 Feb, 2025 at 11:50 AM by Chris Sandu

MIS Department Policy & Procedure

Document Name:	Procedure-Security Cameras Museum	Document Type:	Procedure
Written by:	/Rochelle Lyon	Date/Revision Date:	09/27/2021

Museum Geovision NVR

Geovision NVR for Museum Security Cameras installed by Vince in 2021. Used with GV Edge Recording Manager software.

Firewall Information

NVR server is located at 172.20.9.23

Virtual IP: 96.27.111.211

Open Ports:

3388

5552

5611

56000 (Stream Port)

Policy #92 on firewall

Access the camera system through the following URL

http://172.20.9.23:80/index.htm

You will need a user name and password from Vince. (See Dashlane)

Use only the following menu options:

Right-click the camera window and select Remote Playback to see a list of recorded events. Select the day at the top and the time in the bottom box.

To save video footage do the following:

Stop video playback (can't export if playing)
Right-Click Remote Playback video screen and select Tools/Save as AVI
Click on the Setting tab and at the bottom change the Codec Selection to WMV9
Click OK
It will display a screen that says the status is Merging. It will take a few minutes. A red bar under Status will indicate progress.
When it says Complete it is ready for download. Click the X in the upper right corner of the Merge box to close it.
To download, Right-Click again in the Remote Playback window and select Tools/Download
Select a folder to save the video to and click OK.
Look in the folder you saved the video to and you will see a folder with the date in it. Open that folder.
Navigate down the subfolders until you see AVI files.
Right-click on an AVI file and select Open With/Windows Media Player

iPhone App Access

Install the app called GV-Eye
Add a system by clicking the plus in the upper right corner.
Configure as follows:
Name=Cityhall
IP Address=96.27.111.211
WebPort=80
Port=56000
Username/Password=See Dashlane
After entering the info, click Get Information to connect and retrieve the camera list.
Once the system is added click on Live in the upper left corner.
Click the Plus in each of the boxes to add cameras to the view.
Swipe right or left for additional pages of cameras.
